SIZE		Polypropylene ISO1346:1990		Polyethylene ISO1969:1990		Polyamide ISO1140:1990		Polyester ISO1141:1990		Vinylon KUROLONKS
Diam. mm	cir . inch	Weight kg/220m	MBL tonf	Weight kg/220m	MBL tonf	Weight kg/220m	MBL tonf	Weight kg/220m	MBL tonf	Weight kg/220m	MBL tonf
4	1/2	1.32	0.21	1.78	0.20	2.31	0.32	2.60	0.30	2.20	0.15
6	3/4	3.74	0.60	4.00	0.40	4.95	0.75	6.00	0.56	5.00	0.33
8	1	6.60	1.06	7.20	0.70	8.80	1.35	10.6	1.02	8.80	0.56
10	1-1/4	9.90	1.56	10.8	1.09	13.6	2.08	16.7	1.59	13.6	0.95
12	1-1/2	14.3	2.21	15.8	1.54	19.6	3.00	24.2	2.27	19.8	1.37
14	1-3/4	20.0	3.05	21.0	2.09	27.0	4.10	32.6	3.18	26.4	1.83
16	2	25.3	3.78	28.0	2.80	35.0	5.30	43.0	4.10	35.2	2.34
18	2-1/4	32.5	4.82	35.0	3.50	44.0	6.70	54.0	5.15	44.0	2.92
20	2-1/2	40.0	5.80	44.5	4.30	54.0	8.30	67.0	6.40	53.9	3.55
22	2-3/4	48.4	6.96	53.0	5.10	66.0	10.0	81.0	7.60	64.9	4.24
24	3	57.0	8.13	65.0	6.10	78.0	12.0	96.0	9.10	78.0	5.00
26	3-1/4	67.0	9.41	72.0	7.00	92.0	14.0	113	10.7	91.0	5.80
28	3-1/2	78.0	10.7	86.0	8.20	107.0	15.8	131	12.2	106	6.64
30	3-3/4	89.0	12.2	101	9.50	122	17.8	150	13.7	120	7.60
32	4	101	13.5	115	10.7	139	20.0	171	15.7	136	8.51
36	4-1/2	129	16.9	145	13.4	176	24.9	216	19.4	173	10.6
40	5	158	20.5	173	16.3	218	30.0	267	24.0	213	12.9
44	5-1/2	194	24.6	209	19.6	264	35.8	323	28.5	258	15.3
48	6	229	28.6	253	22.8	312	42.0	385	33.6	306	18.0
52	6-1/2	268	33.1	290	26.4	365	48.8	451	39.2	359	21.0
