SIZE		POLYESTER ROPES		POLYPROPYLENE AND POLYESTER MIXED ROPE
Diam.(mm)	Circle(inch)	Kg/220m	Bbreaking Load(TON)	Kg/220m	Breaking Load(TON)
20	2-1/2	67	6.4	51	5.76
24	3	96	9.1	72	8.19
28	3-1/2	131	12.2	95	11.0
32	4	171	15.7	125	14.1
36	4-1/2	216	19.4	147	17.5
40	5	267	24.0	192	21.6
44	5-1/2	323	28.5	227	26.6
48	6	385	33.6	312	30.2
52	6-1/2	451	39.2	319	35.3
56	7	524	44.8	369	40.3
60	7-1/2	600	49.9	426	45.0
64	8	684	58.0	483	52.3
72	9	864	72.1	616	65.0
80	10	1067	88.5	759	79.7
88	11	1291	106	910	95.4
96	12	1537	126	1082	113
104	13	1804	145	1108	130
112	14	2090	160	1408	148
120	15	2398	190	1697	171
